Transformer Vacuum Drying Equipment

Vacuum Drying Equipment for Oil-immersed Transformers

TRANFOVIA Transformer Vacuum Drying Equipment is designed for drying oil-immersed transformers, capacitors, motors and related electrical products. The system combines vacuum drying with hot-air circulation to improve drying efficiency and can be configured with a micro-water measuring instrument, terahertz heating plates and full process-data recording.

Applications

This Transformer Vacuum Drying Equipment is used for controlled moisture removal from insulation systems in oil-immersed transformer, capacitor and motor production. The system is selected when the manufacturing process requires hot-air-assisted vacuum drying, optional moisture-output monitoring, accelerated heating options and complete process records before subsequent assembly or oil filling.

Vacuum Drying Features for Transformer Production

• Hot-air circulation

The drying system uses hot-air circulation to enhance drying efficiency inside the vacuum drying process.

• Optional micro-water measurement

A micro-water measuring instrument can be added to display the water output rate during processing.

• Optional terahertz heating plates

Terahertz heating plates can be supplied, with a listed drying-time reduction of 30%-50% for the supported configuration.

• Process traceability

Complete production-process parameter records can be retained for subsequent traceability.

Vacuum Drying Equipment vs. Vapour Phase Drying Equipment

FAQ

1. What is transformer vacuum drying equipment used for?

It is used for drying oil-immersed transformers, capacitors, motors and other approved electrical products as part of the manufacturing process.

2. Can the drying process be monitored?

Yes. A micro-water measuring instrument is available as an option to display the water output rate.

3. Can the drying cycle be shortened?

Optional terahertz heating plates are listed with a potential drying-time reduction of 30%-50% for the supported configuration.

4. Is this the same as vapour phase drying equipment?

No. This system uses hot-air circulation for vacuum drying. Vapour phase drying uses a different working medium and has its own VPD model range and distillation configuration.

5. What data should be supplied for a vacuum drying plant quotation?

Provide workpiece dimensions, maximum batch load, desired cycle, plant utilities, moisture-monitoring requirement, enhanced-heating requirement and process-recording requirement.
